Programmer Temperature Controller

The E62 PID Controller is purpose-built for precise and stable temperature control applications. Utilizing a robust PID logic algorithm, it ensures enhanced stability and responsive performance across a wide range of thermal environments.

The controller supports popular thermocouple (TC) types J, K, T, R, S and RTD (PT100) inputs, making it versatile for various industrial and laboratory settings. Its dual-color high-brightness LCD display, IP65-rated front panel, and user-friendly interface offer a seamless and reliable user experience.

Designed for value, the E62 combines advanced features with competitive pricing, making it a smart choice for diverse temperature control needs. Connect | Contact

Get A Quote

Key Features:

PID Control Algorithm: Enhanced stability and precision

Auto-Tuning: Automatic parameter optimization for optimal control

Display: Dual-color high-brightness LCD

Input Compatibility:

Thermocouples (TC): Types J, K, T, R, S

RTD: PT100 (DIN standard)

Communication: RS485 support

Sampling Rate: 5 samples/second (200 ms interval)

Resolution: 18-bit A/D input, 15-bit D/A output

Protection: IP65 front panel, parameter lockout for secure operation

Sensor Break Detection:

Thermocouples/RTD: open circuit

RTD: short circuit detection

4-20mA: <1mA considered break

1-5V: <0.25V considered break

Break Detection Response Time:≤ 4 seconds (TC & RTD)

Electrical Ratings:

Input Voltage Range: -2VDC to +12VDC (Max)

Features:

High-brightness LCD display
200ms sampling rate
PID control
RS485 communication
Parameter lockout protection
High-accuracy 18-bit A-D input and 15-bit D-A output
Input signals: TC (J, K, T, R, S), RTD (PT100)
Auto-tuning

Signal Input

Type: Thermocouple(J,K,T,R,S), RTD(PT100(DIN)

Resolution: 18 Bits

Sampling rate: 5 Times / Second (200msec)

Maximum rating: -2VDC minimum, 12VDC maximum

Sensor break detection:

Sensor open for Thermocouple and RTD inputs, sensor short for RTD input , below 1mA for 4-20mA input, below 0.25V for 1-5V input, not available for other inputs

Sensor break responding time: Within 4 seconds for Thermocouple and RTD inputs
